產品信息
| 產品型號 | 額定功率 | 額定力矩 | 額定轉速 | 額定電流 | 峰值扭矩 | 峰值電流 |
| (Kw) | (Nm) | (rpm) | (Arms) | (Nm) | (Arms) | |
| 220VAC電壓 | ||||||
| HXA70-5030A | 0.5 | 1.6 | 3000 | 2.3 | 3.4 | 19.1 |
| HXA70-7345A | 0.73 | 1.55 | 4500 | 3.3 | 3.4 | 30.5 |
| HXA70-6930A | 0.69 | 2.2 | 3000 | 3 | 5.2 | 30.5 |
| HXA70-9445A | 0.94 | 2 | 4500 | 4.3 | 5.2 | 30.5 |
| HXA70-8530A | 0.85 | 2.72 | 3000 | 4.1 | 7 | 42 |
| HXA70-1145A | 1.15 | 2.43 | 4500 | 5.9 | 7 | 18.5 |
| HXA10-1330A | 1.35 | 4.3 | 3000 | 5.4 | 11.8 | 19.1 |
| HXA10-1745A | 1.79 | 3.8 | 4500 | 8 | 11.8 | 30.5 |
| HXA10-1830A | 1.82 | 5.8 | 3000 | 8.2 | 17.7 | 30.5 |
| HXA10-2245A | 2.21 | 4.7 | 4500 | 9 | 17.7 | 42 |
| HXA10-1117A | 1.14 | 6.3 | 1725 | 59 | 17.7 | 18.5 |
| HXA10-1417A | 1.46 | 8.1 | 1725 | 5.9 | 23.6 | 22.8 |
| HXA10-2025A | 2.02 | 3 | 5 | 9.2 | 23.6 | 36.9 |
| 380VAC電壓 | ||||||
| HX70-7950B | 0.79 | 1.5 | 5000 | 2.1 | 3.4 | 6 |
| HX70-1050B | 1.02 | 1.95 | 5000 | 2.6 | 5.2 | 8.5 |
| HX70-1250B | 1.24 | 2.36 | 5000 | 3.5 | 7 | 12 |
| HXA10-1850B | 1.88 | 3.6 | 5000 | 4.9 | 11.8 | 19.1 |
| HXA10-2350B | 2.36 | 4.5 | 5000 | 6.8 | 17.7 | 20.5 |
| HXA10-1830B | 1.82 | 5.8 | 3000 | 5 | 17.7 | 18.5 |
| HXA10-2330B | 2.36 | 7.5 | 3000 | 5.6 | 23.6 | 22.8 |
| HXA10-2943B | 2.93 | 6.5 | 4 | 6.5 | 23.6 | 36.9 |
